Body

Figure 7504 · Rear Moulding

8 genuine catalog part numbers · Production from 2024-04

Open interactive figure

Toyota Taisor Rear Moulding exploded parts diagram, figure 7504 — AMS Allied watermarked Toyota Taisor reference diagram.

Part numbers in this diagram

8 parts

Garnish Sub-assy, Back Door, Outside

PNC 76801

Protector, Back Door Outside Garnish

PNC 76825

Cover, Back Door Garnish

PNC 76839B

Cover, Back Door Garnish

PNC 76839C

Clip, Back Door Outside Garnish

PNC 76817

Diagram Hardware / Fastener

PNC 90118WCE48

Diagram Hardware / Fastener

PNC 90118WCU40

Diagram Hardware / Fastener

PNC 90118WC063
