Body

Figure 7104 · Seat Belt & Child Restraint Seat

8 genuine catalog part numbers · Production from 2024-04

Open interactive figure

Toyota Taisor Seat Belt & Child Restraint Seat exploded parts diagram, figure 7104 — AMS Allied watermarked Toyota Taisor reference diagram.

Part numbers in this diagram

8 parts

Belt Assy, Front Seat Inner, Rh

PNC 73230

Belt Assy, Front Seat Inner, Lh

PNC 73240

Belt Assy, Rear Seat 3 Point Type, Outer Rh

PNC 73360

Diagram Hardware / Fastener

PNC 90118WC103

Diagram Hardware / Fastener

PNC 90118WC108

Diagram Hardware / Fastener

PNC 90118WC165

Diagram Hardware / Fastener

PNC 90118WC166

Diagram Hardware / Fastener

PNC 90118WC050
