Carpet, Luggage Compartment Floor
PNC 64711D
Body
Figure 6404 · Deck Board & Deck Trim Cover
21 genuine catalog part numbers · Production from 2024-04
Part numbers in this diagram
21 partsPanel Assy, Deck Trim Side, Rh
PNC 64730B
Panel Assy, Deck Trim Side, Rh
PNC 64730B
Panel Assy, Deck Trim Side, Lh
PNC 64740C
Panel Assy, Deck Trim Side, Lh
PNC 64740C
Suspender Sub-assy, Package Tray Trim
PNC 64306
Panel Assy, Package Tray Trim
PNC 64330D
Pad, Package Tray Trim Silencer, Rear
PNC 64335
Cushion, Package Tray Trim
PNC 64377
Hinge, Package Tray Trim, Rh
PNC 64361
Hinge, Package Tray Trim, Lh
PNC 64362
Hanger, Package Tray Trim
PNC 64381A
Cover, Deck Trim, Rear
PNC 64716D
Cover, Deck Trim, Rear
PNC 64716D
Cover, Deck Trim Service Hole
PNC 64718D, 64718E
Cover, Deck Trim Side Lamp Hole
PNC 64746A
Cover Assy, Spare Wheel
PNC 64770D
Clip(for Deck Trim Side Panel)
PNC 64730H
Clip(for Deck Side Trim Panel)
PNC 64730K, 64750F
Diagram Hardware / Fastener
PNC 90118WC589
Diagram Hardware / Fastener
PNC 90118WC050
