Powertrain / Chassis

Figure 3312 · Shift Lever & Retainer

34 genuine catalog part numbers · Production from 2024-04

Open interactive figure
Toyota Taisor Shift Lever & Retainer exploded parts diagram, figure 3312
AMS Allied watermarked Toyota Taisor reference diagram.

Part numbers in this diagram

34 parts
33524-WC001

Bracket, Control Lever Housing Support (for Floor Shift)

PNC 33524F

33524-WC004

Bracket, Control Lever Housing Support (for Floor Shift)

PNC 33524F

33530-WC020

Lever Assy, Shift (for Floor Shift)

PNC 33530F

33530-WC021

Lever Assy, Shift (for Floor Shift)

PNC 33530F

33550-WC032

Lever Assy, Shift (for Floor Shift)

PNC 33530F

33823-WC004

Bracket, Transmission Control Cable, No.1

PNC 33823
