Pedal Sub-assy, Clutch
PNC 31301
Powertrain / Chassis
Figure 3102 · Clutch Pedal & Flexible Hose
18 genuine catalog part numbers · Production from 2024-04
Part numbers in this diagram
18 partsHose, Clutch
PNC 31418
Tube, Clutch Master Cylinder To Flexible Hose
PNC 31481
Tube, Clutch Master Cylinder To Flexible Hose
PNC 31481
Tube, Clutch Master Cylinder To Flexible Hose
PNC 31481
Pad, Clutch Pedal
PNC 31321
Support Sub-assy, Clutch Pedal
PNC 55107A
Shaft, Clutch Pedal
PNC 31324
Bush(for Clutch Pedal)
PNC 31301C
Cushion, No.1(for Clutch Pedal)
PNC 31301B
Collar, Clutch Pedal Shaft
PNC 31324A
Spring(for Clutch Pedal)
PNC 31301A
Clamp(for Clutch Master Cylinder Tube)
PNC 31481M
Clamp(for Clutch Tube)
PNC 31482C
Diagram Hardware / Fastener
PNC 90118WC079
Diagram Hardware / Fastener
PNC 90118WC164
Diagram Hardware / Fastener
PNC 90118WC782
Diagram Hardware / Fastener
PNC 90118WC686
