Pipe, Water Inlet
PNC 16322
Tool / Engine / Fuel
Figure 1603 · Radiator & Water Outlet
63 genuine catalog part numbers · Production from 2024-04
Part numbers in this diagram
63 partsPipe, Water Inlet
PNC 16322
Hose, Water Outlet
PNC 16335A
Hose, Water Inlet
PNC 16262
Protector, Hose Heat
PNC 16279A
Hose, Water By-pass
PNC 16261
Hose, Water By-pass
PNC 16283B
Hose, Turbo Water, No.1
PNC 16284
Hose, Water By-pass
PNC 16283B
Inlet, Water
PNC 16321
Inlet, Water
PNC 16321
Pipe, Water Inlet
PNC 16322
Pipe, Water Inlet
PNC 16322
Housing Sub-assy, Water Inlet
PNC 16302
Housing Sub-assy, Water Inlet
PNC 16302
Housing Sub-assy, Water Inlet
PNC 16302
Housing Sub-assy, Water Inlet
PNC 16302
Ring, O(for Water Inlet Housing)
PNC 16323C
Gasket, Water Inlet Housing, No.1
PNC 16325
Gasket, Water Inlet Housing
PNC 16325A
Thermostat
PNC 16331A
Thermostat
PNC 16331A
Blower Assy, W/shroud
PNC 16360
Blower Assy, W/shroud
PNC 16360
Fan
PNC 16361
Motor, Cooling Fan
PNC 16363
Insulator, Cooling Fan Motor
PNC 16366A
Hose, Radiator Tank
PNC 16423
Radiator Assy
PNC 16400
Radiator Assy
PNC 16400
Cap Sub-assy, Radiator
PNC 16401
Plug, Radiator Drain Cock
PNC 16400B
Tank Assy, Radiator Reserve
PNC 16470
Cap Sub-assy, Reserve Tank
PNC 16471
Packing(for Radiator Drain Cock)
PNC 16400F
Cushion, Sub-radiator Support
PNC 16523
Hose, Radiator, No.2
PNC 16572D
Hose, Radiator, No.2
PNC 16572D
Hose, Radiator, No.1
PNC 16571C
Hose, Radiator, No.1
PNC 16571C
Bracket, Radiator, No.1
PNC 16582
Shroud, Fan
PNC 16711
Shroud, Fan
PNC 16711
Ring, O(for Water Inlet Pipe)
PNC 16302E
Clamp Or Clip, Hose(for Water By-pass Hose)
PNC 16261V, 16283C
Clamp Or Clip, Hose(for Water By-pass Hose)
PNC 16261A
Clip, Radiator Hose, No.1
PNC 16571D, 16572E
Support, Radiator, Lower
PNC 16535
Support, Radiator, Lower
PNC 16535
Clip(for Water Inlet Hose)
PNC 16262A, 16283C, 16284A
Diagram Hardware / Fastener
PNC 90118WCG27
Diagram Hardware / Fastener
PNC 90118WC017
Diagram Hardware / Fastener
PNC 90118WC015
Diagram Hardware / Fastener
PNC 90118WC078
Diagram Hardware / Fastener
PNC 90118WC002
Diagram Hardware / Fastener
PNC 90118WC023
Diagram Hardware / Fastener
PNC 90118WC129
Diagram Hardware / Fastener
PNC 90118WCC48
Diagram Hardware / Fastener
PNC 90118WCT46
Diagram Hardware / Fastener
PNC 90118WC223
Diagram Hardware / Fastener
PNC 90118WCT76
Diagram Hardware / Fastener
PNC 90118WC005
Diagram Hardware / Fastener
PNC 90118WCT72
