Body

Figure 7501 · Emblem & Name Plate (exterior & Interior)

9 genuine catalog part numbers · Production from 2023-08

Open interactive figure

Toyota Rumion Emblem & Name Plate (exterior & Interior) exploded parts diagram, figure 7501 — AMS Allied watermarked Toyota Rumion reference diagram.

Part numbers in this diagram

9 parts

Plate, Back Door Name, No.2

PNC 75442A

Plate, Back Door Name, No.2

PNC 75442A

Plate, Back Door Name, No.2

PNC 75442A

Plate, Back Door Name, No.2

PNC 75442A

Plate, Back Door Name, No.1

PNC 75441E

Emblem, Radiator Grille (or Front Panel)

PNC 75311

Emblem, Symbol

PNC 75741E

Plate, Back Door Name, No.3

PNC 75443

Diagram Hardware / Fastener

PNC 9016750063
