Armrest Assy, Rear Rh
PNC 74250
Body
Figure 7401 · Armrest & Visor
16 genuine catalog part numbers · Production from 2023-08
Part numbers in this diagram
16 partsArmrest Assy, Rear Lh
PNC 74260
Visor Assy, Rh
PNC 74310
Visor Assy, Lh
PNC 74320
Visor Assy, Lh
PNC 74320
Holder, Visor
PNC 74348
Grip Assy, Assist
PNC 74610S
Grip Sub-assy, Assist
PNC 74610A
Extinguisher Assy
PNC 74710
Extinguisher Assy
PNC 74710
Diagram Hardware / Fastener
PNC 90118WCE47
Diagram Hardware / Fastener
PNC 9046705172
Diagram Hardware / Fastener
PNC 9167380822
Diagram Hardware / Fastener
PNC 9155180635
Diagram Hardware / Fastener
PNC 9167180635
Diagram Hardware / Fastener
PNC 9322915020
