Figure 6708 · Back Door Panel & Glass

18 genuine catalog part numbers · Production from 2023-08

Open interactive figure

Toyota Rumion Back Door Panel & Glass exploded parts diagram, figure 6708 — AMS Allied watermarked Toyota Rumion reference diagram.

Part numbers in this diagram

18 parts

67005-WC014

Panel Sub-assy, Back Door

PNC 67005

67005-WC016

Panel Sub-assy, Back Door

PNC 67005

67005-WC020

Panel Sub-assy, Back Door

PNC 67005

67751-WC008

Board, Back Door Trim

PNC 67751

67881-WC004

Weatherstrip, Back Door

PNC 67881A

68105-WC008

Glass, Back Door

PNC 68131

68105-WC009

Glass, Back Door

PNC 68131

74811-WC001

Handle, Door Pull

PNC 74811D

90118-WC265

Clip(for Back Door Trim Board)

PNC 67751A

90118-WCF58

Cushion(for Back Door Panel)

PNC 67005B

90118-WC528

Diagram Hardware / Fastener

PNC 90118WC528

90118-WCF63

Diagram Hardware / Fastener

PNC 90118WCF63

90118-WC832

Diagram Hardware / Fastener

PNC 90118WC832

90118-WC211

Diagram Hardware / Fastener

PNC 90118WC211

90118-WC077

Diagram Hardware / Fastener

PNC 90118WC077

56116-WC001

Diagram Hardware / Fastener

PNC 56116WC001

90118-WCA09

Diagram Hardware / Fastener

PNC 90118WCA09

90118-WC595

Diagram Hardware / Fastener

PNC 90118WC595
