Panel Sub-assy, Instrument, Upper
PNC 55302A
Body
Figure 5501 · Instrument Panel & Glove Compartment
57 genuine catalog part numbers · Production from 2023-08
Part numbers in this diagram
57 partsPanel Sub-assy, Instrument, Lower
PNC 55303B
Reinforcement Assy, Instrument Panel
PNC 55330B
Cushion, Instrument Panel, No.1
PNC 55355
Cushion, Instrument Panel
PNC 55355E
Cushion, Instrument Panel, No.2
PNC 55356C
Seal, Instrument Cluster Finish Panel, No.1
PNC 55468C
Panel Sub-assy, Instrument Panel Finish, Lower
PNC 55045
Panel Sub-assy, Instrument Panel Finish, Lower
PNC 55045
Garnish, Instrument Cluster Finish Panel, Lower
PNC 55479D
Garnish, Instrument Cluster Finish Panel, Lower
PNC 55479D
Panel Sub-assy, Instrument Cluster Finish, Center
PNC 55405B
Panel Sub-assy, Instrument Cluster Finish, Center
PNC 55405B
Panel, Instrument Panel Finish, Lower
PNC 55432B
Panel, Instrument Panel Finish, Lower
PNC 55432B
Panel Assy, Instrument Cluster Finish
PNC 55410C
Panel, Instrument Cluster Finish, Center
PNC 55412D
Panel Assy, Instrument Cluster Finish, Center
PNC 55420A
Base, Switch Hole, No.1
PNC 55446A
Garnish, Instrument Cluster Finish Panel
PNC 55474B
Garnish, Instrument Cluster Finish Panel, Center
PNC 55475B
Cover, Stereo Opening, No.2
PNC 55521F
Cover, Stereo Opening
PNC 55521C
Cover, Spare Switch Hole
PNC 55539
Cover, Spare Switch Hole, No.2
PNC 55539B
Cap, Instrument Panel Safety Pad
PNC 55458A
Door Assy, Glove Compartment
PNC 55550
Cover, Glove Compartment Door Pad
PNC 55553B
Cover, Glove Compartment Door Side
PNC 55428A
Cushion(for Glove Compartment Door)
PNC 55510A
Cushion, Instrument Panel
PNC 55349A
Cushion, Glove Compartment
PNC 55045D
Cushion, Glove Compartment Door Check
PNC 55557A
Panel Sub-assy, Instrument Panel Finish, Lower
PNC 55045
Cover Sub-assy, Instrument Panel Under, No.2
PNC 55607
Register Assy, Instrument Panel, No.2
PNC 55660
Register Assy, Instrument Panel, No.1
PNC 55650
Register Assy, Instrument Panel, Lower No.1
PNC 55680
Register Assy, Instrument Panel, No.3
PNC 55670
Airbag Assy, Instrument Panel Passenger W/o Door
PNC 73960A
Cap
PNC 55434E
Clip, Instrument Panel Finish, Lower Center
PNC 55434D
Diagram Hardware / Fastener
PNC 90118WC145
Diagram Hardware / Fastener
PNC 90118WC064
Diagram Hardware / Fastener
PNC 90118WC572
Diagram Hardware / Fastener
PNC 90118WCF32
Diagram Hardware / Fastener
PNC 90118WC150
Diagram Hardware / Fastener
PNC 90118WC212
Diagram Hardware / Fastener
PNC 90118WC824
Diagram Hardware / Fastener
PNC 90118WCJ20
Diagram Hardware / Fastener
PNC 90118WCS84
Diagram Hardware / Fastener
PNC 9046705172
Diagram Hardware / Fastener
PNC 9046705171
Diagram Hardware / Fastener
PNC 9046808048
Diagram Hardware / Fastener
PNC 9356855014
Diagram Hardware / Fastener
PNC 90167C0004
Diagram Hardware / Fastener
PNC 9018305094
