Powertrain / Chassis

Figure 3312 · Shift Lever & Retainer

30 genuine catalog part numbers · Production from 2023-08

Open interactive figure
Toyota Rumion Shift Lever & Retainer exploded parts diagram, figure 3312
AMS Allied watermarked Toyota Rumion reference diagram.

Part numbers in this diagram

30 parts
33524-WC002

Bracket, Control Lever Housing Support (for Floor Shift)

PNC 33524F

33530-WC002

Lever Assy, Shift (for Floor Shift)

PNC 33530F

33550-WC022

Lever Assy, Shift (for Floor Shift)

PNC 33530F

33550-WC023

Lever Assy, Shift (for Floor Shift)

PNC 33530F

33823-WC004

Bracket, Transmission Control Cable, No.1

PNC 33823

33866-WC001

Spring, Compression (for Shift Lock Release Button)

PNC 33563A

33880-WC005

Cable Assy, Parking Lock (for Floor Shift)

PNC 33880A
