Pipe, Water Inlet
PNC 16322
Tool / Engine / Fuel
Figure 1603 · Radiator & Water Outlet
34 genuine catalog part numbers · Production from 2023-08
Part numbers in this diagram
34 partsPipe, Water Inlet
PNC 16322
Inlet, Water
PNC 16321
Housing Sub-assy, Water Inlet
PNC 16302
Housing Sub-assy, Water Inlet
PNC 16302
Gasket, Water Inlet Housing, No.1
PNC 16325
Thermostat
PNC 16331A
Shroud, Fan
PNC 16711
Hose, Radiator Tank
PNC 16423
Radiator Assy
PNC 16400
Cap Sub-assy, Radiator
PNC 16401
Plug, Radiator Drain Cock
PNC 16400B
Tank Assy, Radiator Reserve
PNC 16470
Cap Sub-assy, Reserve Tank
PNC 16471
Cushion, Radiator Support
PNC 16523A
Hose, Radiator, No.1
PNC 16571C
Hose, Radiator, No.2
PNC 16572D
Clamp Or Clip(for Water By-pass Hose)
PNC 16261R
Hose, Water By-pass, No.1
PNC 16261G
Hose, Water By-pass, No.2
PNC 16261N
Hose, Radiator Tank
PNC 16423
Clip(for Water By-pass Hose No.1)
PNC 16261H, 16261P
Clip, Radiator Hose, No.1
PNC 16571D
Support, Radiator, Lower
PNC 16535
Bracket, Radiator, No.1
PNC 16582
Bracket, Radiator, No.2
PNC 16583
Ring, O(for Water Inlet Pipe)
PNC 16302E
Diagram Hardware / Fastener
PNC 90118WC078
Diagram Hardware / Fastener
PNC 90118WCT22
Diagram Hardware / Fastener
PNC 90118WC023
Diagram Hardware / Fastener
PNC 90118WC021
Diagram Hardware / Fastener
PNC 90118WC017
Diagram Hardware / Fastener
PNC 90118WC129
Diagram Hardware / Fastener
PNC 90118WC015
