Figure 1601 · Water Pump

17 genuine catalog part numbers · Production from 2023-08

Open interactive figure

Toyota Rumion Water Pump exploded parts diagram, figure 1601 — AMS Allied watermarked Toyota Rumion reference diagram.

Part numbers in this diagram

17 parts

16100-WC009

Pump Assy, Engine Water

PNC 16100

16173-WC003

Pulley, Water Pump

PNC 16173

16271-WC001

Ring, O(for Water Pump)

PNC 16100H

16603-WC003

Pulley Assy, Idler

PNC 16630G

16620-WC004

Tensioner Assy, V-ribbed Belt

PNC 16620

16620-WC005

Tensioner Assy, V-ribbed Belt

PNC 16620

16620-WC006

Tensioner Assy, V-ribbed Belt

PNC 16620

16631-WC001

Bracket, Idler Pulley

PNC 16631

90118-WCL75

Diagram Hardware / Fastener

PNC 90118WCL75

90118-WC022

Diagram Hardware / Fastener

PNC 90118WC022

90118-WC078

Diagram Hardware / Fastener

PNC 90118WC078

90118-WC005

Diagram Hardware / Fastener

PNC 90118WC005

90118-WC023

Diagram Hardware / Fastener

PNC 90118WC023

90118-WC099

Diagram Hardware / Fastener

PNC 90118WC099

90118-WC027

Diagram Hardware / Fastener

PNC 90118WC027

90118-WC651

Diagram Hardware / Fastener

PNC 90118WC651

90118-WCJ33

Diagram Hardware / Fastener

PNC 90118WCJ33
