Panel Sub-assy, Windshield Header
PNC 63102A
Body
Figure 6104 · Roof Panel & Back Window Glass
93 genuine catalog part numbers · Production from 2024-01
Part numbers in this diagram
93 partsPanel Sub-assy, Windshield Header
PNC 63102A
Reinforcement Sub-assy, Roof Panel, Center
PNC 63104
Reinforcement Sub-assy, Roof Panel
PNC 63103A
Panel, Roof
PNC 63111
Panel, Roof
PNC 63111
Panel, Roof
PNC 63111
Reinforcement, Roof Panel, No.1
PNC 63141G
Reinforcement, Roof Panel, No.2
PNC 63142
Reinforcement, Roof Panel, No.3
PNC 63143B
Frame Sub-assy, Back Door Opening
PNC 63105A
Bracket, Roof Panel Reinforcement
PNC 63147
Reinforcement, Roof Panel, No.4
PNC 63144B
Weatherstrip, Roof
PNC 63161
Bracket, Inner Mirror Base
PNC 63171B
Rail Sub-assy, Slide Roof
PNC 63202H
Rail Sub-assy, Slide Roof
PNC 63202H
Panel Sub-assy, Roof Wind Deflector
PNC 63209
Panel Sub-assy, Roof Wind Deflector
PNC 63209
Glass, Roof Window
PNC 63212A
Glass, Roof Window
PNC 63212A
Garnish, Sliding Roof, Front Rh
PNC 63217E
Garnish, Sliding Roof Side, Lh
PNC 63218R
Cable, Sliding Roof Drive, Rh
PNC 63223A
Cable, Sliding Roof Drive, Rh
PNC 63223
Cable, Sliding Roof Drive, Rh
PNC 63223A
Cable, Sliding Roof Drive, Rh
PNC 63223
Cable, Sliding Roof Drive, Lh
PNC 63224A
Cable, Sliding Roof Drive, Lh
PNC 63224
Cable, Sliding Roof Drive, Lh
PNC 63224A
Cable, Sliding Roof Drive, Lh
PNC 63224
Link, Roof Wind Deflector Lifter, Rh
PNC 63225D
Link, Roof Wind Deflector Lifter, Rh
PNC 63225D
Link, Roof Wind Deflector Lifter, Lh
PNC 63226B
Link, Roof Wind Deflector Lifter, Lh
PNC 63226B
Panel, Sliding Roof Housing
PNC 63233C
Panel, Sliding Roof Housing
PNC 63233C
Hose, Sliding Roof Drain
PNC 63249E
Hose, Sliding Roof Drain
PNC 63249F
Hose, Sliding Roof Drain
PNC 63249G
Strength Sub-assy, Roof Panel
PNC 63021B
Strength Sub-assy, Roof Panel
PNC 63021B
Gear Sub-assy, Sliding Roof Drive
PNC 63260A
Gear Assy, Sliding Roof Drive
PNC 63260H
Gear Sub-assy, Sliding Roof Drive
PNC 63260A
Gear Assy, Sliding Roof Drive
PNC 63260H
Bracket, Sunshade Trim Lock, No.1
PNC 63331H
Bracket, Sunshade Trim Lock, No.1
PNC 63331H
Bracket, Sunshade Trim Lock, No.2
PNC 63332E
Bracket, Sunshade Trim Lock, No.2
PNC 63332E
Garnish, Sliding Roof Side, Rh
PNC 63217G
Garnish, Sliding Roof Side, Lh
PNC 63218G
Garnish, Sliding Roof Side, Rh
PNC 63217K
Garnish, Sliding Roof Side, Lh
PNC 63218M
Garnish, Removable Roof Holder
PNC 63685A
Cover, Removable Roof Holder
PNC 63686A
Pad, Roof Silencer, No.21
PNC 63691, 63692
Pad, Roof Silencer, No.21
PNC 63691
Glass Sub-assy, Rear Slide Roof
PNC 63801C
Glass Sub-assy, Rear Slide Roof
PNC 63801C
Weatherstrip, Rear Slide Roof
PNC 63813
Link Sub-assy, Roof Panel Rh
PNC 63021C
Link Sub-assy, Roof Panel Rh
PNC 63021C
Link Sub-assy, Roof Panel, Lh
PNC 63022C
Link Sub-assy, Roof Panel, Lh
PNC 63022C
Holder, Sliding Roof Guide Rail, Rh
PNC 63257E
Holder, Sliding Roof Guide Rail, Lh
PNC 63258G
Clamp, Sliding Roof Drain Hose
PNC 63236D
Bolt, Sliding Roof Glass
PNC 63212E, 63801D
Screw, Roof Wind Deflector Panel
PNC 63209A
Screw, Sliding Roof Drive Gear
PNC 63260P, 63260Q
Set Plate, Frme Front, Rh
PNC 63202K
Set Plate, Frme Front, Lh
PNC 63202L
Set Plate, Frme Rear, Rh
PNC 63202M
Set Plate, Frme Rear, Lh
PNC 63202N
Fastener, Slide Roof Rail
PNC 63202P
Screw, Frme Set Plate
PNC 63202C, 63331J
Bolt, Sliding Roof Glass
PNC 63212E, 63801D
Screw, Roof Wind Deflector Panel
PNC 63209A
Screw, Sliding Roof Drive Gear
PNC 63260P, 63260Q
Set Plate, Frme Front, Rh
PNC 63202K
Set Plate, Frme Front, Lh
PNC 63202L
Set Plate, Frme Rear, Rh
PNC 63202M
Set Plate, Frme Rear, Lh
PNC 63202N
Fastener, Slide Roof Rail
PNC 63202P
Screw, Frme Set Plate
PNC 63202C, 63331J
Diagram Hardware / Fastener
PNC 90118WC565
Diagram Hardware / Fastener
PNC 90118WC050
Diagram Hardware / Fastener
PNC 90118WC057
Diagram Hardware / Fastener
PNC 90118WC160
Diagram Hardware / Fastener
PNC 90118WCN11
Diagram Hardware / Fastener
PNC 90118WCM73
Diagram Hardware / Fastener
PNC 90118WC015
