Hood Sub-assy
PNC 53301
Body
Figure 5302 · Hood & Front Fender
23 genuine catalog part numbers · Production from 2024-01
Part numbers in this diagram
23 partsInsulator, Hood
PNC 53341B
Seal, Hood To Radiator Support
PNC 53381
Protector, Front Fender Side Panel, Lh
PNC 53828K
Panel, Front Fender, Rh
PNC 53811A
Panel, Front Fender, Lh
PNC 53812C
Protector, Front Fender, Upper Rh
PNC 53825A
Protector, Front Fender, Upper Rh
PNC 53825A
Protector, Front Fender, Upper Lh
PNC 53826A
Protector, Front Fender, Upper Lh
PNC 53826A
Protector, Front Fender Side Panel, Lh
PNC 53828B
Protector, Front Fender Side Panel, Rh
PNC 53827L
Pad, Front Wheel Opening Extension, Rh
PNC 53851D
Liner, Front Fender, Rh
PNC 53875A
Liner, Front Fender, Lh
PNC 53876A
Cushion
PNC 53936C
Clip, Front Fender Side Panel Protector, No.1
PNC 53827Q
Clip(for Hood Insulator)
PNC 53341C, 53875C
Protector, Front Fender Side Panel, Rh
PNC 53827K
Diagram Hardware / Fastener
PNC 90118WC015
Diagram Hardware / Fastener
PNC 90118WC152
Diagram Hardware / Fastener
PNC 90118WC260
Diagram Hardware / Fastener
PNC 90118WCA23
