Actuator Or Upper Bracket Assy, Steering Lock
PNC 45020B
Powertrain / Chassis
Figure 4501 · Steering Column & Shaft
19 genuine catalog part numbers · Production from 2024-01
Part numbers in this diagram
19 partsActuator Or Upper Bracket Assy, Steering Lock
PNC 45020B
Cover, Steering Column
PNC 45286
Column Sub-assy, Electric Power Steering
PNC 4520A
Column Sub-assy, Electric Power Steering
PNC 4520A
Column Sub-assy, Electric Power Steering
PNC 4520A
Column Sub-assy, Electric Power Steering
PNC 4520A
Seal, Dust
PNC 45231B
Protector, Steering Column, No.1
PNC 45874B
Shaft Assy, Steering Intermediate, No.2
PNC 45260
Cover Sub-assy, Steering Column Hole, No.1
PNC 45025D
Bolt, Steering Lock Set
PNC 45897
Ring, O(for Steering Column Hole Cover)
PNC 45025A
Diagram Hardware / Fastener
PNC 90118WC078
Diagram Hardware / Fastener
PNC 45897WC005
Diagram Hardware / Fastener
PNC 90118WC119
Diagram Hardware / Fastener
PNC 90118WC140
Diagram Hardware / Fastener
PNC 90118WC056
Diagram Hardware / Fastener
PNC 90118WCM55
