Board Assy, Deck
PNC 58410B
Body
Figure 6404 · Deck Board & Deck Trim Cover
34 genuine catalog part numbers · Production from 2023-04
Part numbers in this diagram
34 partsBoard, Deck, No.1
PNC 58411A
Board, Deck, No.2
PNC 58412A
Board, Deck, No.3
PNC 58438B
Board, Deck, No.3
PNC 58438B
Mat Assy, Rear Floor
PNC 58570A
Carpet Assy, Rear Floor
PNC 58570D
Mat Assy, Rear Floor
PNC 58570A
Mat, Rear
PNC 58557A
Suspender Sub-assy, Package Tray Trim
PNC 64306
Panel Assy, Package Tray Trim
PNC 64330D
Pad, Package Tray Trim Silencer, Rear
PNC 64335
Cushion, Package Tray Trim
PNC 64377
Hinge, Package Tray Trim, Rh
PNC 64361
Hinge, Package Tray Trim, Lh
PNC 64362
Hanger, Package Tray Trim
PNC 64381A
Cover, Deck Trim, Rear
PNC 64716D
Cover, Deck Trim Service Hole
PNC 64718A
Cover, Deck Trim Service Hole
PNC 64718D
Cover, Deck Trim Service Hole
PNC 64718D
Cover, Deck Trim Service Hole
PNC 64718A
Panel Assy, Deck Trim Side, Rh
PNC 64730B
Panel Assy, Deck Trim Side, Rh
PNC 64730B
Panel Assy, Deck Trim Side, Rh
PNC 64730B
Panel Assy, Deck Trim Side, Rh
PNC 64730B
Panel Assy, Deck Trim Side, Lh
PNC 64740C
Panel Assy, Deck Trim Side, Lh
PNC 64740C
Panel Assy, Deck Trim Side, Lh
PNC 64740C
Panel Assy, Deck Trim Side, Lh
PNC 64740C
Cover, Deck Trim Side Lamp Hole
PNC 64746A
Box Sub-assy, Tool, No.1
PNC 75201C
Box Sub-assy, Tool, No.1
PNC 75201C
Clip(for Deck Trim Rear Cover)
PNC 64716E
Diagram Hardware / Fastener
PNC 90118WC265
