Electrical

Figure 8121 · Interior Lamp

18 genuine catalog part numbers · Production from 2022-08

Open interactive figure
Toyota Hyryder Interior Lamp exploded parts diagram, figure 8121
AMS Allied watermarked Toyota Hyryder reference diagram.

Part numbers in this diagram

18 parts
81080-WC001

Lamp Assy, Interior Illumination, No.1

PNC 81080J

81080-WC004

Lamp Assy, Interior Illumination, No.1 Rh

PNC 81080H, 81080T

81230-WC013

Lamp Assy, Interior Illumination, No.1 Lh

PNC 81080L, 81080U
